由奥特曼支持的Volantis公布计划,通过将光子学融入AI加速器来跨越内存墙Altman-backed Volantis reveals plan to vault the memory wall by baking photonics into AI accelerators

点「原文对照」整页切到原文,或双击某段只看那段的原文。

Sam Altman支持的AI芯片初创公司Volantis有一个利用光突破内存墙的计划,这一次它不仅仅是一个IP游戏。这家总部位于旧金山的初创公司成立于2022年,正在开发一种人工智能加速器,该加速器将使用光子插入器来大幅增加内存带宽,而不会影响容量。Volantis相信它可以以高达240 TB/s的速度将10 TB以上的内存打包到一个巨大的包中。

Sam Altman-backed AI chip startup Volantis has a plan to break through the memory wall using light, and this time it's not just an IP play. Founded in 2022, the San Francisco-based startup is developing an AI accelerator that will use a photonic interposer to dramatically increase memory bandwidth without compromising on capacity. Volantis believes it can pack upwards of 10 TB of memory at speeds up to 240 TB/s onto a single massive package.

它声称,这应该足以为每个用户10,000 tok/s的20万亿参数模型提供服务。为了做到这一点,瓦兰蒂斯采取了一种有点不寻常的方法。该公司没有开发一些新颖的计算架构或存储器技术,而是将精力集中在光学插入器上。它计划从IP提供商那里获得许可的所有其他内容。“差异主要来自光学插入器。那么,为什么我们不绝对许可我们所能许可的一切,即使它不是世界上最高的性能,因为我们已经通过插入器和集成来承担了很多风险,”首席执行官塔帕·戈什(Tapa Ghosh)告诉El Rege。

This, it claims, should be enough to serve a 20 trillion parameter model at 10,000 tok/s per user. To do this, Volantis is taking a somewhat unusual approach. Rather than developing some novel compute architecture or memory technology, the company is focusing its efforts on the optical interposer. Everything else it plans to license from IP providers. "The differentiation is primarily coming from the optical interposer. So why don't we license absolutely everything we possibly can, even if it's not the highest performance in the world, because we're already biting off a lot of risk with the interposer and the integration," CEO Tapa Ghosh tells El Reg.

Volantis称其为A-1的芯片背后的基本理念,通过使用光导管而不是电互连,可以显着增加每个封装的高带宽存储器数量。由于大多数AI加速器内存(如HBM)的运行速度以及所使用的数据管脚的大小和数量,它需要尽可能靠近计算,以最大限度地减少功耗并最大限度地提高信号完整性。因此,现代图形处理器的最大容量和带宽受到计算芯片海岸线的限制。

The basic idea behind the chip, which Volantis is calling A-1, is that by using optical wave guides rather than electrical interconnects it can dramatically increase the amount of high-bandwidth memory per package. Because of the speeds at which most AI accelerator memory, like HBM, operate, and the size and number of data pins used, it needs to be as close to the compute as possible to minimize power consumption and maximize signal integrity. As a result the maximum capacity and bandwidth of modern GPUs is limited by the compute die's shoreline.

这是芯片周围的物理边界。目前,这意味着AMD MI 455 X的上限约为432 GB。光互连可以延伸得更远。内存可以位于几厘米之外,而不是几毫米,从而消除了海岸线作为瓶颈。

That's the physical perimeter around the chip. For now, that means the cap is right around 432 GB on AMD's MI455X. Photonic interconnects can extend that much farther. Instead of a few millimeters the memory can be located a few centimeters away, eliminating the shoreline as a bottleneck.

虽然HBM作为一个有用的例子,但我们要注意的是,Volantis尚未透露其芯片将使用什么存储技术。Volantis的目标是使用集成到插入器中的光导管来实现这一目标。其合作伙伴设计或提供的计算和存储器将打包在上面。如果这些听起来很熟悉的话,那么瓦兰蒂斯并不是第一个提出以这种方式使用硅光插入器的人。正如我们的姐妹网站Next Platform之前报道的那样,Lightmatter和Celestial AI过去都曾考虑过这个想法。

While HBM is useful as an example, we'll note Volantis hasn't said what memory tech its chip will use just yet. Volantis aims to achieve this using optical waveguides integrated into an interposer. Compute and memory designed or supplied by its partners will be packaged on top. If any of this sounds familiar, Volantis isn't the first to propose using silicon photonic interposers in this manner. As our sister site Next Platform has previously reported, both Lightmatter and Celestial AI have toyed with the idea in the past.

事实上,我们强烈怀疑HBM远程的想法导致了Marvell决定以55亿美元收购Celestrian。然而,与Celestial或Lightmatter不同的是,Volantis并没有试图将其技术授权给其他芯片制造商。至少现在还没有。相反,它的目标是开发一个成熟的推理芯片。“至少在第一天,这是一个更容易展示交付的解决方案的问题,”戈什说。

In fact, we strongly suspect the idea of HBM-at-a-distance contributed to Marvell's decision to acquire Celestial for $5.5 billion. However, unlike either Celestial or Lightmatter, Volantis isn't trying to license its tech to other chipmakers. At least not yet. Instead it aims to develop a fully fledged inference chip. "It is, at least on day one, a way easier problem to demonstrate a solution that ships," Ghosh says.

另一个差异化因素是初创公司中介层所基于的技术。瓦兰蒂斯的设计不依赖外部激光器,而是使用微型垂直腔面发射激光器(简称微型闭路电视),这意味着光源直接集成到插入器中。VCSEL无论如何都不是新事物,但其可靠性一直受到批评。然而,Volantis首席技术官Roy Meade告诉我们,近年来该技术已经取得了长足的进步,通过放弃一些速度,可以实现更高的可靠性,他将这一理念描述为广泛而高效。

Another differentiator is the technology on which the startup's interposer is based. Rather than relying on external lasers, Volantis' design uses micro vertical-cavity surface-emitting lasers — micro-VCSELs for short — and means the light source is integrated directly into the interposer. VCSELs aren't new by any means, but have faced criticism over their reliability. However, Volantis CTO Roy Meade tells us the technology has come a long way in recent years and by giving up some speed, significantly higher reliability can be achieved, a philosophy he describes as wide and efficient.

他说:“人们仍然受制于此,我称之为胖管点对点的心态,自然,如果是这样的话,你会走向SerDes。”“如果我们回过头来看看一个广泛而有效的方法的好处。例如HBM。采用同样的剧本很有意义。“米德的意思是,互连可以通过几种不同的方式实现更高的带宽。

"People are still constrained to this, what I would call a fat pipe point-to-point mentality, and naturally, if that's the case, you're going to go towards SerDes," he says. "If we were to go back and take a look at the benefits of a wide-and-efficient approach. HBM for example. Taking that same playbook makes a lot of sense." What Meade is getting at is that interconnects can achieve higher bandwidth in a couple different ways.

第一个是提高链接速度,第二个是使用更多链接。例如,可以使用四条200 Gbps链路或八条100 Gbps链路来实现800 Gbps链路。在他的HBM示例中,通过使用极宽的接口来实现更高的带宽,但相对于其他存储器技术,每个引脚的数据速率较慢。同样的概念也适用于Volantis的基于光学插入器的加速器。功率效率仍然是一个困扰许多光电子初创公司的悬而未决的问题,但这对Volantis来说可能不是一个问题,因为它并没有试图授权其第一代插入器技术。

The first is by increasing the link speed, and the second by using more links. For example an 800 Gbps link can be achieved using four 200 Gbps links or eight 100 Gbps links. In his example of HBM, higher bandwidth is achieved by using an extremely-wide bus but slower data rate per pin relative to other memory technologies. The same concept applies to Volantis' optical interposer-based accelerator. Power efficiency remains an open question that's dogged many photonics startups, but this may be less of a problem for Volantis because it's not trying to license its first-gen interposer tech.

该公司的第一款产品的目标是每24 Gbps通道每位1皮焦,系统总功率约为20千瓦。Volantis在制作第一个可生产的芯片之前还有很长的路要走,并且需要筹集更多的风险投资来实现这一目标--远远超过本周在Lachy Groom、Abstract Ventures和其他公司的帮助下筹集的8800万美元。戈什很清楚这一点。他表示,这笔资金将使该公司能够从小规模光学演示设备扩展到更接近最终产品的产品。

For its first product the company is targeting 1 picojoule per bit per 24 Gbps lane and a total system power of around 20kW. Volantis still has a ways to go before it tapes out its first production-ready chip, and will need to raise a fair bit more in venture capital to do that — far more than the $88 million it raised this week with the help of Lachy Groom, Abstract Ventures, and others. Ghosh is well aware of this. He says the funding will enable the company to scale from small-scale optical demonstrators to something more closely resembling the final product.

仅插入器就足够具有挑战性,但实际集成他们许可的IP也很复杂。“积极地说,我们应该在12到18个月内推出MVP产品作为我们的目标,”他告诉我们,并指出这是为了拥有一个工作原型,而不是批量生产。®

The interposer alone is challenging enough, but then there is the complexity of actually integrating the IP they license. "Aggressively, we should aim for an MVP product in 12 to 18 months as our target," he tells us, noting that's to have a working prototype not volume production. ®
